110kv CCV production line

The products is controlled by ISO9000 quality system.(We selt the whole cable production line ,we sell single machine as well) 1.Controlled by computer and operated by touch srceen, communicates with profibus. 2.Adopt¢65 conductor shield,¢150 insulation,¢90 insulation shield, triple-layer co-extrusion. 3.Controlled by field density,shifting phase trigger function of tubes. 4.The specially designed triple-layer co-extrusion crosshead ensure the joint speed raising not to eccentric after modulating with low speed and can made finished cable after 30-40m. 5.The man-machine communicate menu can deposited the technological parameter to use at any moment. 110kv high voltage catenary Triple-layer Co-extrusion Dry-cure CCV production line Parameter: voltage class: XLPE 6 110kv. Wire section: copper35 630mm². aluminum:50 800mm2 Max cable weight:16Kg/m. Max Diameter:¢75mm. Pipe-laying form: Half catenary suspersion. Nitrogen:pressure2.0-2.5MP purity:99.5%. Consumption:0.4 1.8m³(standard atmospherc pressure), volume of nitrogen tank:5m³. Cooling water:pressure:0.2 0.6Mpa circulation25m³. Compressed air:pressure:0.6 0.8Mpa, normal dossage0.8m³. Installed capacity:1000KVA. Total Weight:100t
