Triple layer co-extruder

The products is controlled by ISO9000 quality system.(We selt the whole cable production line ,we sell single machine as well) 1.The Whole line adopt PLC programming control and touching screen operation that havehigh automation and accurate control. 2.Make sure the devices arrangements (mainly imported equipments) to be best. 3.High efficiency, stable product quality, observable economic benefit. Parameter: ¢65 Extruder Type:¢65/20 Ratio of length to diameter: 20:1 DC motor: 30KW Screw size: Type of BM spearation Speed of rotation:67r/min Extrusion out put: 35kg/h Max extrusion temperature:135oC Working pressure of the barrel:70MPa Capacity of thrust bearing:788KN Speed reducing ratio of gearbox:32:1 Heating of the barrel:3×3KW ¢90Extruder Type:¢90/20 Ratio of length to diameter: 20:1 DC motor: 55KW Screw size: Type of BM spearation Speed of rotation:55r/min Extrusion out put: 60kg/h Max extrusion temperature:135oC Working pressure of the barrel:70MPa Capacity of thrust bearing:1040KN Speed reducing ratio of gearbox:27.71:1 Heating of the barrel:4×4KW ¢150Extruder Type:¢150/25 Ratio of length to diameter: 25:1 DC motor: 132KW Screw size: Type of BM spearation Speed of rotation:45r/min Extrusion out put: 250kg/h Max extrusion temperature:140oC Working pressure of the barrel:50MPa Capacity of thrust bearing:1600KN Speed reducing ratio of gearbox:37.5:1 Heating of the barrel:6×9KW
